Ethernet Connection

Specification

Specification	Value
Connector Type	M12 Ethernet
Coding	X-coded
Category	Cat6a

Pinout

Pin	Signal	Pair
1	TD1+	2
2	RD1-	2
3	TD2+	3
4	RD2-	3
5	TD4+	4
6	RD4-	4
7	RD3-	1
8	TD3+	1
